OEMs Choose NyoGel® 760G to Prevent Electrical Failures
The Leading Connector Grease
When parts need to be repaired or routinely serviced, OEMs must be prepared to issue recommended products and solutions. These bulletins play an important role in ensuring that dealerships or service providers provide their customers with the right solution that will solve current issues and/or prevent future problems from occurring.
While almost all connectors work flawlessly when cars are rolling fresh off the assembly line, the true reliability of the electrical system of a car only becomes apparent after the cars are exposed to their harsh everyday operating conditions:
- Constant vibration and shock
- Extreme temperatures & humidity
- Exposure to ice melt, saltwater, dirt and dust
Over many decades, Nye has helped several prominent OEMs with their costly recall campaigns by providing a field fix for connector failures that could have been avoided by using Nye's Connector Grease, NyoGel® 760G, in the initial design. NyoGel® 760G is the universal standard for dielectric grease specified by leading OEMs across many industries. The grease was engineered to improve the functionality, reliability, and longevity of electrical connectors, switches, printed circuit boards, and wire nuts.
| Typical Properties | NyoGel® 760G | Test Methods |
|---|---|---|
| Chemistry | PAO/Silica | - |
| Temperature Range | -40 to 135 °C | - |
| Kinematic Viscosity (40 °C) | 400 cSt | ASTM D445 |
| Viscosity Index | 147.5 | ASTM D2270 |
| Water Washout (1 h, 80 °C) | 2% | ASTM D1264 |
| Salt Spray Resistance (750 h) | No Corrosion | ASTM B117-18 |
| Dielectric Breakdown Voltage | 11.2 kV | CTM |
Advantages of NyoGel® 760G
- Extends the functional life of components.
- Improves the reliability of connections.
- Seals and protects components from environmental elements.
- Prevents fretting wear and corrosion.
- Reduces insertion force.
- Insulates against electrical short circuits.
- Specified by: Ford (WSB-M1C239-A), GM (9986087, 12377900, 1645644), FCA (MS-9469, 04661991, 05013781AA) and others.
Easy Application
NyoGel® 760G is offered in 110-pound kegs, 7-pound pails, 30cc syringes, and 100-gram tubes to suit different dispersing needs. See our Dispensing Brochure for our list of recommended dispensing companies.
Service Bulletins
Below is a list of service bulletins where NyoGel® 760G is listed as the recommended maintenance solution for components experiencing issues related to fretting corrosion, water intrusion, and/or oxidation.
| Company | Component | Manual |
|---|---|---|
| BAE Systems | HybriDrive® | System Manual 401393-397 |
| Caterpillar Inc. | Fuel Injectors | Service Bulletin 03-40-001 |
| C. E. Niehoff & Co. | C510 Alternator |
Field Service Tip SB0016A |
| Daimler Trucks North America |
DEF Gauge Stuck | Service Bulletin 49-7 |
| EATON, Roadranger | Input Shaft Sensor for Hybrid Transmissions Lightning 18-way ECU Connector |
Service Bulletin TAIB0847 Service Bulletin TMIB-0156 |
| Emerson Climate Technologies | Copeland Discus™ Compressors | Service Bulletin AE8-1368 R2 |
| General Motors | Brake Lights and Powertrain, Braking, and Suspension Control Modules | Service Bulletin 09-06-03-004A Service Bulletin 09-06-03-004B Service Bulletin 09-06-03-004C Service Bulletin 09-06-03-004D |
| Harley Davidson | Diagnostic Trouble Codes P2135 and P2101 | Technical Document TT418 |
| Hyundai | Control Wiring Harness Sensors Connections |
Service Bulletin 03-40-001 Service Bulletin SB02006 |
| MACK | Engine Power Distribution Module (EPDM) Terminal Corrosion | Service Bulletin SB725003 |
| Molex | Lubrication of Mini-Fit SR. Tin Plated Terminals | Service Bulletin AS-42815-001 |
| Navistar, Inc. | - | AC Bus Operation and Maintenance Manual: 0000001425 3915018R2 Operation and Maintenance Manual: 0000001581 2645901R5 ProStar+ Operation Manual: 0000001301 3933971R5 |
* These service bulletins were not issued by Nye Lubricants. Please contact the corresponding OEM for more information regarding the bulletin in question.
